Medium Voltage Cable Parameter
Conductor material: copper, aluminum, alloy, etc.
Conductor cross-sectional area: 25-2500mm2
Insulation layer: EPR/XLPE/HDPE, etc.
Sheath material: PVC/PUR/PE/LSZH, etc.
Armor layer: steel wire, steel belt, etc.
Voltage level: medium voltage
Number of cores: single core, 2 cores, 3 cores or multi-cores
Minimum bending radius: flexibility greater than 8 times the outer diameter of the cable, rigidity greater than 10D
Is customization supported: yes
Highly Reliable Medium Voltage Cable
Hengxun’s conventional medium voltage cable uses XLPE insulation, has excellent electrical properties and heat resistance, and is widely used in medium voltage transmission projects. Due to its rigorous design and excellent insulation performance, its failure rate is extremely low, and its design life is more than 30 years. All cables comply with IEC60840 standards, so please feel free to choose.
Medium Voltage Cable for Various Environments
Whether your project is overhead, buried or submarine, we provide you with a variety of medium voltage cables.For overhead installation, we use aluminum conductors, which are lighter and cheaper. For dynamic installation, we provide you with flexible insulation and steel wire braid protection. For mining, we use ERP insulation and steel wire armor to ensure that it is well adapted to each environment.
First, pay attention to the protection of the cable and add an armored sheath; second, pay attention to the bending radius during laying to prevent the cable from being damaged.
Single-core medium voltage cable is suitable for long-distance power transmission or high current carrying occasions.
Medium voltage cable using copper conductors has a higher current carrying capacity and is relatively more expensive, while aluminum conductors are lighter and less expensive.
